The product is used to display the time in hours

and minutes. The display takes place by means of
LEDs. The product is approved only for operation
in dry rooms. Use other than that described above
will lead to damage to the product and also involves
additional risks.

SAFETY INSTRUCTIONS AND DANGER

WARNINGS

The guarantee will lapse if damage is occurred as

a result of non-compliance with these operating in-
structions! The guarantee will lapse in such cases.

For safety and licensing (CE) reasons, unauthor-

ized conversion and/or modifications to the product
are not permitted.

The device may not be exposed to extreme tem-

peratures (<0°C/>+50°C), strong vibration or heavy
mechanical stress. There is risk of damage!

The plug-in unit is constructed according to

protection class II.

The product is approved only for operation in

dry rooms.

Never pour any liquids on the appliance. You run

the risks of causing a fire or fatal electric shock! If
liquid or any other object penetrates the appliance,

disconnect the main plug immediately and contact
a specialist.

Only a specialist may replace a damaged plug-in

or damaged connection cable. There is risk of fatal
electric shock!

Only a 230V/50Hz socket may be used as

the source of power for the plug-in power unit.
Never try to operate the appliance on any other
voltage.

Always unplug the plug-in power unit out of the

socket by the casing, never by the cable!

The plug-in power unit may never be plugged in

or taken out with wet hands.

Always unplug the plug-in power unit from the

socket!

– before cleaning the appliance
– during thunderstorms
– if you will not be using the appliance for a long

period.

The product is not a toy and must be kept out of

reach of children. Children cannot estimate the risks
which can arise because of incorrect handling of
electrical appliances.

Do not leave the packing material lying around

carelessly. Plastic foil and/or bags and polystyrene

parts ect. can become dangerous toys in the hands
of children.

Never switch on the device immediately after it

have been taken from a cold to a warm room. The
condensate can destroy the device under certain
circumstances. Let the device to reach room
temperature before switching it on. Wait until the
condensate water vaporize.

Only use the supplied plug-in power unit for the

power supply of the clock.

The unit may not be opened.
The device is not suitable for commercial use.

FEATURES

CONNECTION OF CLOCK

Plug the plug-in power unit low voltage plug (small

plug on the cable) into the low-voltage jack, which
is located on the side of the clock. Then plug the
plug-in power unit into a 230V/50Hz socket. The
display of the clock will appear.

Always withdraw the plug-in power unit first from

the socket before you take the low-voltage plug
out of the clock.

ADJUSTING CLOCK

The adjusting buttons are located on the back

side of the clock.

Adjusting the hours:
• Hold down the key [TIME] (the display flashes).

Now press the button [HOUR] as well. Hold down
both keys until the desired hour is set.

Adjusting the minutes:
• Hold down the key [TIME] (the display flashes).

Now press the button [MIN] as well. Hold down both
keys until the desired minute is set.

USE AS A WALL CLOCK

When setting up the device, make sure that the

base is stable. When hanging up the device, make

sure that the attachment is secure. If the appliance
falls, it can injure people or break.

Wall clock:
Pay attention when mounting that no power, gas

or water pipes are damaged by mistake! Danger
of death!

When mounting on the wall, use screws and

dowels which are suitable for the composition of
the wall.

Do not place the clock near the sources of dis-

turbance such as PC, mobile phones etc. Always
keep a distance at least 50 cm from such sources
of disturbance.

Use the two attachment holes on the back of the

clock as a drilling model. Drill two corresponding
holes in the wall and insert the dowels (if they are
necessary). For the clock to be attached correctly,
the screws should have a distance of approximately
4 mm between the lower side of the screw head and
the wall. Hang up the clock on the two screws.

MAINTAINANCE AND DISPOSAL

The outside of the device should be cleaned with

a soft, slightly damp cloth or a dry brush. Do not
use any aggressive cleaning liquids or chemical
solutions, as they may damage the device.

When the device has become unusable, dispose

it in accordance with the current statutory regula-
tions.

Note: Due to electromagnetic discharge or dis-

turbances clock may not function correctly. For
example, the display may not change. And there
will be «RESET» on it. To eliminate the error with-
draw the plug-in power unit from the socket. Wait
around 10 minutes and then plug it into the socket
again. The clock will be reset, and you’ll have to
set the time again.

After withdrawing the plug-in power unit, the time

will be stored for about 10 seconds after that the
clock has to be set again.

TECHNICAL DATA

P l u g - i n p o w e r u n i t o p e r a t i n g v o l t a g e :

230V/50Hz

Operating voltage, clock: 12 V

JUMBO LED WALL CLOCK

Model AH-1081
