Serial Communications
Vidikron PlasmaView Owner’s Operating Manual 51
PRE
L
IMINAR
Y
Pixel Protect Manual - Lum.
Setting:
AUTO
LEVEL 1
LEVEL 2
LEVEL 3
DFH 80H 60H 6BH 03H 01H
02H
03H
04H 30H
(=01/01/01) ...
37H
(=04/03/03)
Manual - Inverse:
OFF
INVERSE
WHITE
DFH 80H 60H 6BH 03H 01H
02H
03H
Manual - Orbiter:
AUTO 1
OFF
AUTO 2
DFH 80H 60H 6BH 03H 01H
02H
03H
Manual - Image
Sweep:
ON
OFF
DFH 80H 60H C8H 04H 01H
02H 00H FFH 01H 8CH
8DH
Manual - Soften:
OFF
1
2
3
4
DFH 80H 60H 65H 01H 01H
02H
03H
04H
05H 26H
27H
28H
29H
2AH
Manual - OSD
Orbiter:
ON
OFF
DFH 80H 60H 5FH 01H 01H
02H 20H
21H
Manual - OSD
Contrast:
LEVEL 2
LEVEL 1
DFH 80H 60H 37H 01H 01H
02H F8H
F9H
CC Mode OFF
CAPTION1
CAPTION2
CAPTION3
CAPTION4
TEXT1
TEXT2
TEXT3
TEXT4 DFH 80H 60H 3CH 01H 00H
01H
02H
03H
04H
05H
06H
07H
08H FCH
FDH
FEH
FFH
00H
01H
02H
03H
04H
CC Contrast LEVEL2
LEVEL1 DFH 80H 60H 3DH 01H 01H
02H FEH
FFH
Table 6-1. Serial Commands (continued)
Function Command
Command
Data
Length
(Bytes)
Data Checksum
