Text mode
Original mode

Vidikron PlasmaView Owner’s Operating Manual

PRE

IMINAR

Pwr. On Select: Select Pwr. On Select from the Function menu to specify which input signal
is displayed when you turn on the PlasmaView. You can also specify an initial audio volume
level.

You can select a specific input or volume level (0 to 42). Or, select LAST to have the
PlasmaView set the input and volume to what they were the last time it was turned off.

Signal Info

Select Signal Info from the Main menu to check the frequencies and polarities of the current
input signal. (If RGB/PC is the current input, “MODE” is replaced by “MEMORY.”)

Press EXIT to return to the Main menu.

INPUT SELECT : RGB

VOLUME

: 22

PWR. ON SELECT

SEL.

ADJ. RETURN

EXIT

H. FREQ : 48.4KHz

V. FREQ : 60.0Hz

H. POLARITY

: NEG.

V. POLARITY

: POS.

MODE : 480i

RESOLUTION : --

SIGNAL INFO

SEL. OK

SEL. OK RETURN

EXIT
