Page 30: Pre l iminar y
20
Vidikron PlasmaView Owner’s Operating Manual
PRE
L
IMINAR
Y
Cable Management
To minimize cable clutter, use the cable clamps provided with the PlasmaView to bundle the
video, audio and control cables at the back of the display. Install the clamps as shown in
Figure 3-5.
Figure 3-5. Installing the Cable Clamps
➤
cables
clamp
mounting hole
Back of the unit
mounting holes
To attach
To detach
1.
2.
