Serial Communications
Vidikron PlasmaView Owner’s Operating Manual 49
PRE
L
IMINAR
Y
Video
Standard 3.58 NTSC
4.43 NTSC
PAL
SECAM
AUTO
PAL60
PAL-M
PAL-N DFH 80H 60H 5CH 01H 01H
02H
03H
04H
0AH
0BH
0DH
0EH
1DH
1EH
1FH
20H
26H
27H
29H
2AH
Background BLACK
GRAY DFH 80H 60H 36H 01H 01H
02H F7H
F8H
Sidebar Lev. 0 (min) ...
15 (max) DFH 80H 60H C6H 01H 00H ...
0FH
86H ...
95H
S1/S2 AUTO
OFF DFH 80H 60H 89H 01H 01H
02H 4AH
4BH
OSD Adjust 1 (TOP L.)
2 (TOP C.)
3 (TOP R.)
4 (BTM. L.)
5 (BTM. C.)
6 (BTM. R.) DFH 80H 60H 1AH 02H 02H 01H
02H
03H
04H
05H
06H DEH
DFH
E0H
E1H
E2H
E3H
ID Remote ALL
1
2
3
4 DFH 80H 60H 2BH 01H 00H
01H
02H
03H
04H EBH
ECH
EDH
EEH
EFH
Factory – 1FH 80H 60H 54H 00H 53H
Auto Off ON
OFF DFH 80H 60H 1AH 02H 03H 01H
02H DFH
E0H
Input Skip ON
OFF DFH 80H 60H 61H 01H 01H
02H 22H
23H
Sub Picture -
Sub P.
Detect OFF
AUTO DFH 80H 60H 7AH 01H 01H
02H 3BH
3CH
Sub Picture -
Sub P. Rate 20%
30%
40%
50%
60%
70%
80%
90%
100% DFH 80H 60H DAH 02H 01H 00H
01H
02H
03H
04H
05H
06H
07H
08H 9CH
9DH
9EH
9FH
A0H
A1H
A2H
A3H
A4H
Table 6-1. Serial Commands (continued)
Function Command
Command
Data
Length
(Bytes)
Data Checksum
