17
Description of each menu
Feature Description min Max Default
Blank Screen
Allows you to select which logo screen will display during
projector start-up.
N/A N/A ViewSonic
Keystone
Vertical Keystone function by using DDP2230 of “TI”
chip to provide vertical keystone correction
-30 +30 0°
Aspect Ratio
Aspect Ratio allows the user to set the aspect ratio of the
image displayed on the projector. This is helpful when the
input resolution is not at the native resolution of the
content or if the user wishes to fill the projector.
1. Fill
2. Native
3. 4:3
4. 16:9
N/A N/A Fill
Magnify To zoom in the details one the projected screen. 0 100 0
Mode
User can choose different mode. Such as User, VGA,
Video and ViewMatch.
N/A N/A
PC: VGA
Component:
Video
Brightness
When Picture mode is selected on User mode, this
function can be active.
Adjusts the brightness of the image. The higher the setting
the brighter the image. And the lower the setting, the
darker the image.
-100 100 0
Contrast
When Picture mode is selected on User mode, this
function can be active.
Adjusts the degree of difference between the dark and
light in the image. The higher the value, the greater the
contrast.
-50 50 0
Sharpness
When Picture mode is selected on User mode, this
function can be active.
Adjusts the image to make it look sharper. (At higher
values, will switch to Detail Enhancement)
0 31 16
Color Space
User can set different Color Space such as Auto, RGB,
YCbCr and YPbPr.
N/A N/A Automatic
Noise
Reduction
Reduce signal noise. But depends on the input signal.
ON OFF ON
Lamp Reset To reset the lamp hours after replaced the lamp. NA NA NA
Factory Reset Return to the factory pre-set value. NA NA NA
HSG
Refer to Page 16, “Fine-tuning the image quality in user
modes”
NA NA NA
Active Source
Shows the input source.
1. VGA
2. Component
NA NA NA
Resolution Shows the current input resolution. NA NA NA
Lamp Hours Shows the current lamp using hours. NA NA NA
The following setup value will be changed after calibration.
Phase Adjusts the clock phase to reduce image distortion.
Tracking Adjusts the image size to fit the screen
Horizontal
Position
Adjusts the horizontal width of the image.
Vertical
Position
Adjusts the Vertical width of the image.
PJD2121 ViewSonic
