Main unit, Parts list – Vertex Standard TRANSCEIVER VX-1700 User Manual
Page 56
56
DESCRIPTION
VALUE
V/W
TOL.
VXSTD P/N
MFR’S DESIG
VERS.
REF.
LOT. SIDE LAY ADR
MAIN Unit
Parts List
C 1196 CHIP CAP.
0.001uF
50V
B
GRM188B11H102KA01D
K22174821
1-
A
I6
C 1197 CHIP CAP.
12pF
50V
CH
GRM1882C1H120JA01D
K22174213
1-
A
I6
C 1198 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
I6
C 1199 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H7
C 1200 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
I7
C 1201 CHIP CAP.
10pF
50V
CH
GRM1882C1H100JA01D
K22174211
1-
A
I7
C 1202 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H5
C 1203 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
I6
C 1204 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
I6
C 1205 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
C5
C 1206 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
I6
C 1207 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H7
C 1208 CHIP TA.CAP.
10uF
10V
TEMSVA1A106M-8R
K78100028
1-
A
I7
C 1209 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H6
C 1210 CHIP CAP.
2pF
50V
CK
GRM1884C1H2R0CZ01D
K22174203
1-
A
H7
C 1211 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H5
C 1212 CHIP TA.CAP.
22uF
10V
TEMSVB21A226M-8R
K78100029
1-
A
I6
C 1213 CHIP TA.CAP.
10uF
10V
TEMSVA1A106M-8R
K78100028
1-
A
B5
C 1214 CHIP TA.CAP.
0.22uF
35V
TESVA1V224M1-8R
K78160027
1-
A
I7
C 1215 CHIP TA.CAP.
1uF
35V
TEMSVA1V105M-8R
K78160032
1-
A
I7
C 1216 CHIP CAP.
0.01uF
25V
B
GRM39B103K25PT
K22144803
1-
A
I7
C 1217 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
B4
C 1218 CHIP CAP.
15pF
50V
CH
GRM1882C1H150JA01D
K22174215
1-
A
H6
C 1219 CHIP CAP.
0.001uF
50V
B
GRM188B11H102KA01D
K22174821
1-
A
H6
C 1220 CHIP CAP.
0.001uF
50V
B
GRM188B11H102KA01D
K22174821
1-
A
H7
C 1222 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H6
C 1223 CHIP TA.CAP.
10uF
16V
TEMSVB21C106M-8R
K78120025
1-
A
H5
C 1224 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H6
C 1225 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H6
C 1226 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G7
C 1227 CHIP TA.CAP.
10uF
16V
TEMSVB21C106M-8R
K78120025
1-
A
H6
C 1228 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G6
C 1229 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H6
C 1230 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G7
C 1231 CHIP CAP.
0.5pF
50V
CK
GRM1884C1HR50CZ01D
K22174201
1-
A
G6
C 1232 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
H6
C 1233 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G6
C 1234 CHIP TA.CAP.
4.7uF
25V
TEMSVB21E475M-8R
K78140019
1-
A
I5
C 1235 CHIP CAP.
0.033uF
16V
R
GRM188R11C333KA01D
K22124801
1-
A
G6
C 1236 CHIP CAP.
0.001uF
50V
B
GRM188B11H102KA01D
K22174821
1-
A
G6
C 1237 CHIP CAP.
0.01uF
25V
B
GRM39B103K25PT
K22144803
1-
A
H6
C 1238 CHIP CAP.
100pF
50V
CH
GRM1882C1H101JA01D
K22174235
1-
A
G7
C 1239 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G6
C 1240 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G6
C 1241 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
E4
C 1242 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G6
C 1243 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G7
C 1244 AL.ELECTRO.CAP.
470uF
16V
RE3-16V471M 470UF
K40129066
1-
A
B6
C 1245 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G6
C 1246 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
G6
C 1247 CHIP TA.CAP.
10uF
10V
TEMSVA1A106M-8R
K78100028
1-
A
F6
C 1249 CHIP CAP.
0.1uF
16V
B
GRM188B11C104KA01D
K22124805
1-
A
A7
C 1250 AL.ELECTRO.CAP.
470uF
16V
RE3-16V471M 470UF
K40129066
1-
A
B6
C 1251 AL.ELECTRO.CAP.
470uF
16V
RE3-16V471M 470UF
K40129066
1-
A
A7
C 1252 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
F6
C 1253 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
F7
C 1254 CHIP CAP.
0.01uF
25V
B
GRM39B103K25PT
K22144803
1-
A
B6
C 1255 CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
1-
A
F6
C 1256 CHIP CAP.
0.1uF
16V
B
GRM188B11C104KA01D
K22124805
1-
A
F7
