Electrical data (standard efficiency), 460 volts three phase, 575 volts three phase – Trane RT-PRC005 User Manual
Page 55
55
RT-PRC005-EN
Electrical
Data
(Standard
Efficiency)
Table ED-5 — Unit Wiring With Electric Heat (Single Point Connection) — Optional Belt Drive — Standard Efficiency
Optional Belt Drive Indoor Motor
To Use
Heater
Heater
Control
Max Fuse Size Orr
Tons
With
Model No.
kW Rating
1
Stages
MCA
Max Circuit Breaker
2
208/230 Volts Single Phase
BAYHTRR105A
N/A
N/A
N/A
N/A
3
TSC036A1
BAYHTRR110A
N/A
N/A
N/A
N/A
BAYHTRR114A
N/A
N/A
N/A
N/A
BAYHTRR105A
N/A
N/A
N/A
N/A
BAYHTRR110A
N/A
N/A
N/A
N/A
4
TSC048A1
BAYHTRR114A
N/A
N/A
N/A
N/A
BAYHTRR118A
N/A
N/A
N/A
N/A
BAYHTRR105A
N/A
N/A
N/A
N/A
BAYHTRR110A
N/A
N/A
N/A
N/A
5
TSC060A1
BAYHTRR114A
N/A
N/A
N/A
N/A
BAYHTRR118A
N/A
N/A
N/A
N/A
208/230 Volts Three Phase
BAYHTRR306A
4.5/6.0
1
21.9/24.3
30/30
3
TSC036A3
BAYHTRR312A
9.0/12.0
2
37.5/42.4
40/45
BAYHTRR318A
13.1/17.4
2
51.6/58.6
60/60
BAYHTRR306A
4.5/6.0
1
25.3/25.3
35/35
4
TSC048A3
BAYHTRR312A
9.0/12.0
2
37.5/42.4
40/45
BAYHTRR318A
13.1/17.4
2
51.6/58.6
60/60
BAYHTRR306A
4.5/6.0
1
30.3/30.3
45/45
BAYHTRR312A
9.0/12.0
2
37.5/42.4
45/45
5
TSC060A3
BAYHTRR318A
13.1/17.4
2
51.6/58.6
60/60
BAYHTRR323A
17.3/23.0
2
66.3/75.4
70/80
460 Volts Three Phase
BAYHTRR406A
6.0
1
12.1
15
3
TSC036A4
BAYHTRR412A
12.0
2
21.1
25
BAYHTRR418A
17.4
2
29.3
30
BAYHTRR406A
6.0
1
13.6
20
4
TSC048A4
BAYHTRR412A
12.0
2
21.1
25
BAYHTRR418A
17.4
2
29.3
30
BAYHTRR406A
6.0
1
15.6
25
BAYHTRR412A
12.0
2
21.1
25
5
TSC060A4
BAYHTRR418A
17.4
2
29.3
30
BAYHTRR423A
23.0
2
37.8
40
575 Volts Three Phase
BAYHTRRW06A
6.0
1
9.3
15
3
TSC036AW
BAYHTRRW12A
12.0
2
16.6
20
BAYHTRRW18A
17.4
2
23.1
25
BAYHTRRW06A
6.0
1
10.0
15
4
TSC048AW
BAYHTRRW12A
12.0
2
16.6
20
BAYHTRRW18A
17.4
2
23.1
25
BAYHTRRW06A
6.0
1
11.8
15
BAYHTRRW12A
12.0
2
16.6
20
5
TSC060AW
BAYHTRRW18A
17.4
2
23.1
25
BAYHTRRW23A
23.0
2
29.8
30
NOTES:
1. Heater kW ratings are at 208/240 for 208/230V unit
2. HACR type circuit breaker per NEC.
