Electrical data (high efficiency) – Trane RT-PRC005 User Manual
Page 51
51
RT-PRC005-EN
Table ED-2 — Unit Wiring — High Efficiency
Optional
Standard Indoor Fan Motor
Oversize Indoor Fan Motor
Belt Drive Indoor Fan Motor
2
Unit
Minimum
Maximum Fuse
Minimum
Maximum Fuse
Minimum
Maximum Fuse
Unit
Operating
Circuit
Size Or Maximum
Circuit
Size Or Maximum
Circuit
Size or Maximum
Tons
Model No.
Voltage Range
Ampacity
Circuit Breaker
1
Ampacity
Circuit Breaker
1
Ampacity
Circuit Breaker
1
THC036A1
187-253
23.9
40
26.3
40
N/A
N/A
3
THC036A3
187-253
16.7
25
19.1
25
19.4
25
THC036A4
414-506
8.3
15
9.5
15
9.7
15
THC036AW
517-633
7.0
15
7.6
15
7.6
15
THC048A1
187-253
29.4
45
31.5
50
N/A
N/A
THC048A3
187-253
21.2
30
23.3
35
22.6
35
4
THC048A4
414-506
11.0
15
12.6
15
11.8
15
THC048AW
517-633
8.3
15
9.1
15
8.5
15
THC060A1
187-253
39.5
60
41.2
60
N/A
N/A
THC060A3
187-253
30.0
45
31.7
45
28.8
45
5
THC060A4
414-506
14.7
20
15.0
20
14.3
20
THC060AW
517-633
11.8
15
12.4
15
11.4
15
THC072A3
187-253
34.8
50
36.1
50
—
—
6
THC072A4
414-506
17.5
25
18.1
25
—
—
THC072AW
517-633
13.5
20
14.3
20
—
—
THC092A3
187-253
38.1
50
41.2
50
—
—
7½
THC092A4
414-506
19.4
25
20.9
25
—
—
THC092AW
517-633
14.8
15
16.0
20
—
—
THC102A3
187-253
42.3
50
45.4
60
—
—
8½
THC102A4
414-506
21.4
25
22.9
30
—
—
THC102AW
517-633
16.6
20
17.8
20
—
—
THC120A3
187-253
48.6
60
52.6
60
—
—
10
THC120A4
414-506
25.3
30
27.3
35
—
—
THC120AW
517-633
19.9
25
21.6
25
—
—
NOTES:
1. HACR breaker per NEC.
Electrical
Data
(High
Efficiency)
