44 RT-PRC005-EN
(10 Ton)
High Efficiency
Performance
Data
Table PD-54— Belt Drive Evaporator Fan Performance — 10-Ton — THC120A3,A4,AW —Horizontal Airflow
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3-HP Standard Motor & Field Supplied 3-HP Standard Motor
Low Static Drive (1) & Drive
3200 — — — — 748 1.06 787 1.19 824 1.32 864 1.47 906 1.64 946 1.81 983 1.97 1015 2.13
3600 746 1.18 777 1.27 811 1.39 849 1.54 883 1.68 916 1.82 950 1.98 987 2.16 1024 2.35 1060 2.55
4000 822 1.59 850 1.70 879 1.81 912 1.95 946 2.12 977 2.28 1006 2.43 1035 2.60 1067 2.79 1101 2.99
4400 898 2.09 925 2.21 950 2.32 977 2.46 1008 2.63 1039 2.81 1067 2.98 1094 3.16 1121 3.33 1147 3.52
4800 974 2.69 1000 2.83 1023 2.95 1046 3.07 1072 3.23 1101 3.42 1130 3.62 1156 3.81 1181 4.00 1206 4.19
5-HP Oversized Motor & Drive
For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:
NOTES: NOTES: NOTES: NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.
5-HP Fan Motor Heat (MBH) = 2.950 x Fan BHP+.470.
1. Field Supplied Motor Sheave 1VM50 x 7/8 inch, Fan Sheave AK89,
and Belt AX40 required
Table PD-54 — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3-HP Standard Motor & Drive
3200 1044 2.28 1072 2.42 1097 2.57 1122 2.71 1145 2.84 1168 2.99 1189 3.12 1210 3.27 1231 3.41 1250 3.54
3600 1093 2.74 1124 2.92 1151 3.09 1176 3.25 1201 3.42 1224 3.58 1246 3.74 1268 3.90 1289 4.06 1308 4.20
4000 1135 3.21 1167 3.42 1198 3.63 1227 3.84 1254 4.05 1278 4.23 1301 4.41 1323 4.60 1344 4.77 1365 4.95
4400 1177 3.73 1207 3.96 1239 4.19 1268 4.42 1297 4.67 1324 4.90 1351 5.12 1376 5.35 1398 5.56 1420 5.75
4800 1229 4.39 1254 4.59 1282 4.83 1310 5.07 1338 5.32 1365 5.58 — — — — — — — —
5-HP Oversized Motor & Drive
Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.
Table PD-55— Belt Drive Evaporator Fan Performance — 10-Ton — THC120A3,A4,AW —Horizontal Airflow — Dehumidification (Hot Gas Reheat)
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2000 — — — — 584 0.43 639 0.53 682 0.62 721 0.71 755 0.79 787 0.88 818 0.97 849 1.06
2400 — — 578 0.48 627 0.57 683 0.70 734 0.83 776 0.94 812 1.05 845 1.15 876 1.26 904 1.36
2800 596 0.58 640 0.67 686 0.79 728 0.90 776 1.04 822 1.19 865 1.34 900 1.47 932 1.60 962 1.73
3200 671 0.85 706 0.93 748 1.06 787 1.19 824 1.32 864 1.47 906 1.64 946 1.81 983 1.97 1015 2.13
***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM. ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM. ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM. ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM. ***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.
NOTES: NOTES: NOTES: NOTES: NOTES:
Data includes pressure drop due to standard filters and wet coils.
Data does not include pressure drop due to reheat coil.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.
1. BAYLSDR010A Required.
2. BAYLSDR010A Required.
Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors, specifically
designed and tested to operate reliably and
continuously at all cataloged conditions. Using the full
horsepower range of our fan motors as shown in our
tabular data will not result in nuisance tripping or
premature motor failure. Our product’s warranty will
not be affected.
Table PD-55 — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3-HP Standard Motor & Drive
2000 877 1.15 906 1.24 933 1.33 961 1.43 988 1.54 1014 1.64 1038 1.74 1063 1.85 1087 1.96 1111 2.07
2400 931 1.47 958 1.58 983 1.68 1008 1.78 1032 1.89 1056 2.00 1080 2.11 1103 2.22 1126 2.34 1149 2.46
2800 989 1.84 1015 1.97 1040 2.09 1064 2.21 1087 2.34 1110 2.46 1132 2.58 1154 2.71 1176 2.83 1196 2.95
3200 1044 2.28 1072 2.42 1097 2.57 1122 2.71 1145 2.84 1168 2.99 1189 3.12 1210 3.27 — — — —
3-HP Standard Motor & Low
Static Drive Accessory Kit (1)
3-HP Standard Motor & Low
Static Drive Accessory Kit (2)
3-HP Oversized Motor & Drive
3-HP Standard Motor & Low
Static Drive Accessory Kit (2)
