General
Data (6 - 10 Ton)
Standard Efficiency
Table GD - 2— General Data
6 Ton 7½ Ton 8½ Ton 10 Ton
Convertible Units Convertible Units Convertible Units Convertible Units
TSC072A3, A4, AW, AK TSC090A3,A4,AW, AK TSC092A3, A4, AW TSC102A3, A4, AW, AK TSC120A3, A4, AW, AK
Cooling Performance 1
Gross Cooling Capacity 72,000 95,000 92,000 105,000 118,000
EER 2 10.3 10.3 10.3 10.3 10.4 6
Nominal CFM / ARI Rated CFM 2,400/2,100 3,000/2,625 3,000/2,625 3,400/3,000 4,000/3,200
ARI Net Cooling Capacity 69,000 90,000 87,000 100,000 7 112,000 7
Integrated Part Load Value (IPLV) 3 — — 11.1 8 11.9 8 11.5 8
System Power (kW) 6.7 8.74 8.45 9.71 9 10.77 9
Compressor
No./Type 1/Scroll 1/Scroll 2/Scrolls 2/Scrolls 2/Scrolls
Outdoor Sound Rating (dB) 4 88 90 87 86 86
Outdoor Coil — Type Lanced Lanced Lanced Lanced Lanced
Tube Size (in.) O.D. 0.3125 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 13.88 17.00 17.00 19.83 25.92
Rows/FPI 2/17 3/17 2/17 2/17 2/17
Indoor Coil — Type Lanced Lanced Lanced Lanced Lanced
Tube Size (in.) 0.3125 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 9.89 9.89 9.89 12.36 12.36
Rows/FPI 2/16 3/16 3/16 3/16 4/16
Refrigerant Control Short Orifice Short Orifice Short Orifice Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT
Outdoor Fan — Type Propeller Propeller Propeller Propeller Propeller
No. Used/Diameter (in.) 1/26 1/26 1/26 1/26 1/26
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1 Direct/1
CFM 6100 6200 6500 7100 7000
No. Motors/HP 1/0.70 11 1/0.70 11 1/0.70 1/0.75 1/0.75
Motor RPM 1115 1115 1115 1115 1115
Belt Drive Indoor Fan — Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used 1 1 1 1 1
Diameter x Width (in.) 12 x 12 12 x 12 12 x 12 15 x 15 15 x 15
Drive Type/No. Speeds Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed
No. Motors 1 1 1 1 1
Motor HP (Standard/Oversized) 1.00/2.00 12 2.00/3.00 2.00/3.00 2.00/3.00 3.00/5.00
Motor RPM (Standard/Oversized) 1750 1750 1750 1750 1750/3450
Motor Frame Size 56 56 56 56 56
Filters — Type Furnished 10 Throwaway Throwaway Throwaway Throwaway Throwaway
(No.) Size Recommended (in.) (4) 16 x 25 x 2 (4) 16 x 25 x 2 (4) 16 x 25 x 2 (4) 20 x 25 x 2 (4) 20 x 25 x 2
Refrigerant Charge (Lbs of R-22) 5 7.1 11.9 6.2 Circuit 1 7.9 Circuit 1 8.4Circuit 1
3.4 Circuit 2 4.0 Circuit 2 6.6 Circuit 2
NOTES:
1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net
and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Certified in accordance with the Unitary Air-Conditioner Equipment
certification program, which is based on ARI Standard 210/240 except AK (380V/60 Hz).
2. SEER is rated at ARI conditions and in accordance with DOE test procedures.
3. Integrated Part Load Value is rated in accordance with ARI Standard 210/240 or 360. Units are rated at 80°F ambient, 80°F entering dry bulb, and 67°F entering wet bulb ar ARI
rated cfm.
4. Outdoor Sound Rating shown is tested in accordance with ARI Standard 270. For more information refer to Table PD-51.
5. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
6. EER shown is for downflow airflow. EER for horizontal airflow is 10.3.
7. ARI Net Cooling Capacity shown is for downflow airflow. Cooling Capacity for Horizontal airflow TSC102A is 99,000; TSC120A is 111,000.
8. Integrated Part Load Value (IPLV) shown is for downflow airflow. IPLV for Horizontal airflow TSC092A is 10.8, TSC102A is 11.5; TSC120A is 11.0.
9. System Power (kW) shown is for downflow airflow. System Power (kW) forHorizontal airflow TSC102A is 9.61; for TSC120A is 10.78.
10. Optional 2” Pleated Filters also available.
11. Outdoor motor is 0.75 hp for AK (380V/60 Hz units).
12. Standard indoor motor is 2.00 hp for AK (380V/60 Hz) units.
