Performance
Data
# Indicates both Standard and High Efficiency.
Table PD-56— Standard Motor & Sheave/Fan Speed (Rpm)
Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn
Tons Model No. Open Open Open Open Open Open Closed
3 T#C036A NA 745 819 894 968 1043 1117
4 T#C048A NA 833 916 1000 1083 1167 1250
5 T#C060A NA 897 987 1077 1166 1256 1346
6 T#C072A N/A 723 779 835 890 946 1002
7½ TSC090,092A N/A 835 891 946 1002 1057 1113
8½ T#C102A N/A 787 847 908 968 1029 1089
10 T#C120A N/A 908 969 1029 1090 1150 1211
Factory set at 3 turns open.
Table PD-57— Standard Motor & High Static Drive Accessory Sheave/Fan Speed (Rpm)
Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn
Tons Model No. Open Open Open Open Open Open Closed
6 T#C072A3,A4,AW N/A 831 895 959 1022 1086 1150
6 TSC072AK N/A 958 1022 1086 1150 1214 1278
7½ TSC090,092A N/A 958 1022 1086 1150 1214 1278
Factory set at 3 turns open.
Table PD-58— Oversized Motor & Drive Sheave/Fan Speed (Rpm)
Unit 6 Turns 5 Turns 4 Turns 3 Turns 2 Turns 1 Turn
Tons Model No. Open Open Open Open Open Open Closed
6 T#C072A3,A4,AW N/A 958 1022 1086 1150 1214 1278
7½ TSC090,092A N/A 1068 1150 1232 1315 1397 1479
8½ T#C102A N/A 958 1022 1086 1150 1214 1278
10 T#C120A 1050 1135 1200 1275 1350 1425 N/A
Factory set at 3 turns open.
Table PD-59— Outdoor Sound Power Level - dB (ref. 10 -12 Watts)
Unit Octave Center Frequency Overall
Tons Model No. 63. 125 250 500 1000 2000 4000 8000 dBA
3 T*C036A 86 83 81 80 78 74 69 68 83
TSC048A1 92 87 84 83 81 76 72 69 86
4 TSC048A3,A4,AW 90 84 78 77 76 72 70 68 82
THC048A 92 86 83 82 81 75 72 69 85
TSC060A 94 87 83 82 79 75 73 69 84
5 THC060A 94 87 82 81 78 74 72 69 84
TSC072A 90 94 90 87 83 78 74 67 88
6 THC072A 91 95 90 87 84 79 75 68 89
TSC090A 92 95 91 88 84 80 75 68 90
7½ TSC092A 89 93 88 85 81 76 72 66 87
THC092A 92 96 92 89 85 80 76 69 91
TSC102A 88 92 87 84 80 75 72 65 86
8½ THC102A 91 95 90 87 84 79 75 68 89
TSC120A 91 88 84 82 81 76 73 67 86
10
THC120A 94 89 87 85 84 78 75 69 88
Note:
Tests follow ARI270-95.
