4 mic off, 5 volume + and – Tandberg Data 3000MXP User Manual
Page 25
3 General Use
21
Example of Side by Side
3.2.4 Mic Off
To mute your microphone during a call, press Mic off. An on-screen indicator appears when
the microphone is off. In a call, if audio is detected, the on-screen symbol will start to flash.
Pressing Mic off one more time will activate the microphone again.
Mic off will mute microphone inputs, but will not mute audio from the AUX and VCR inputs.
Be aware that many calls are connected automatically with Mic off, because the Auto
Answer settings are On+Mic off (see chapter 4.1.4 Auto Answer). The icon will start to
flash when you start speaking. Remember to turn the microphone on before a meeting.
3.2.5 Volume + and -
Press the Volume key to adjust the volume level. An on-screen indicator will show the current
level.
