Overview
Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 2
Range vs. Throughput
The following table shows approximate maximum ranges (at recommended fade margins) achievable with the
M5580M-FSU when associated with an M5830S-AP in CCK mode. Ranges for OFDM modes will be published when
available.
Table – 1 Range & Throughput (CCK mode)
Antenna 3 miles 6 miles 10 miles
Integrated 8 dBi Patch
9 Mbps
(5 db fade margin)
NA NA
Attached to 18” Dish
(AD5800-25) 9 Mbps
(22 db fade margin) 9 Mbps
(15 db fade margin) 9 Mbps
(10 db fade margin)
