Appendix B Specifications
Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 29
Appendix A Specifications
All specifications apply to M5580M-FSU unless otherwise noted.
Data Parameters
Modulation Format
CCK
Certification/Compliance FCC Part 15.247, 15.407: ETSI/EN301 489-1 (7.2) (pending)
Receiver Sensibility –83 dBm (1600 byte packet) to –87 dBm (64 byte packet)
EIRP 29dBm (8dBi Internal Antenna
User Data Throughput 10Mbps
Format 10/100 BaseT 10/100 BaseT
Network Protocols All IEEE 802.3 / 802.3u compliant protocols
Configuration and Management Telnet, TFTP, HTTP, SNMP (via AP only)
Upstream/Downstream Throughput CIR/MIR (Control by the AP)
Physical Interfaces
Ethernet Speed (via RJ45 shielded) 10/100 BaseT, Auto-sensing
Ethernet Packet Up to 3600 byte long packets (supports VLAN/VPN pass through)
POWER PARAMETERS
Power Method Power-over-Ethernet (PoE). DC Voltage injected at PoE J-Box
Voltage input limits into PoE J-Box 10.5 VDC - 20 VDC, 20 VDC Nominal
Voltage input limits into Radio 10.5 VDC – 20 VDC
Standard Power Supply (included) 120 VAC to 20 VDC
PoE Cat-5 Max Cable length 100 meters on 24 AWG STP Cat-5 Cable
Current Draw/Power 600 mA max. (12 W), using 20V standard adapter
Environmental
Radio Enclosure All-weather, powder coated, aluminum case/back with UV stabilized ABS radome
Temperature Range -40
° to 60° C (-40° to 140° F)
NEMA Rating NEMA 4
Radio Dimensions 14.5 in. x 14.5 in. x 3.75 in. (INT) / 6.5 in. x 6.5 in. x 1.5 in (EXT)
Radio Weight 1 Lbs. (45 Kg)
User Interfaces RJ45 (shielded)
