E2-3
2. SPECIFICATIONS ENGLISH VERSION EO1-33014
2.6 External DC Input
2.7 Battery
2.6 External DC Input
Item Description
Conditions Input voltage: DC9V ± 5%
Input current: Max. 8A
Connector specification Printer side: TCP7361-11-0201
Adapter side: TCS7361-01
Connector pin arrangement Pin1: DC9V, Pin2: GND, Pin3: NC
Item Description
Battery Lithium ion battery pack 7.2 VDC, 3000 mAh (Official capacity)
Charge method Battery charger
Charge current 1.0 A
Standard charge voltage 8.5 V ± 0.1 V
Charge time Approx. 4.0 hours
Battery capacity A fully charged battery allows the printer to print about 200 labels
Under the temperature 25°C, it can print 400 to 500 labels.
(Label pitch: 63.5 mm)
Current consumption 3.0 A (when printing bar codes)
Charge and discharge cycle 300 cycles
Protection circuit Overcharge protection circuit (Max. 8.5V)
Option Name Type Description
Battery Pack B-415-BT Lithium ion battery pack
7.2VDC, 3000mAh (Official capacity)
Battery Charger B-415-CHG A charger which is exclusive for the B-415-BT battery pack
AC 100V to 240V, Charge time: Approx. 4hours
NOTE: To purchase the OPTIONAL KIT, please contact your authorized TOSHIBA TEC representa-
tive or TOSHIBA TEC Head Quarter.
2.8 Option
