Tascam CD-VT1MKII - Manual (Page 23)

TASCAM CD-VT1MKII —
23
Disc types 8 cm single, 12 cm
CD
AD/DA 16-bit
Nominal output level
(LINE OUT) –10 dBV
Maximum output level
(LINE OUT) without
distortion 0 dBV (1 Vrms)
Output impedance 1 kΩ
Maximum output level
(PHONES) > 18mW (into 32 $ )
Nominal input levels
LINE IN
MIC IN ( 1 / 2)
–10 dBV
–40 dBV
Voltage requirements DC 9V (PS-PS5 AC
adapter)
AA batteries x 4
(NiMH or alkaline)
Power consumption 4 W (PS-PS5 AC
adapter)
Dimensions (w x d x h)
including feet 232 x 138 x 40
(mm) / 9.1 x 5.4 x
1.6 (in)
Weight (excluding
batteries) 620g / 1 lb, 6 oz.
CD playback characteristics
Frequency response
20 Hz to 20 kHz
±1.0 dB
Dynamic range > 88 dB
S/N ratio > 88 dB
THD < 0.01%
Digital signal processing 32-bit
 Specifications and the appearance
of the CD-VT1MKII may change
without notice for improvement
reasons.
 The illustrations in this manual
may differ slightly from the actual
product.
Facts and figures (specifications)
