Tascam CD-VT1MKII - Manual (Page 19)

TASCAM CD-VT1MKII —
19
(continued from the previous page)
Tap the
CD EFF/SETUP key to enter
the CD Effect menu, and select SPLT by
pressing either the PREV or NEXT key.
Press the UP or DOWN key to select
from the following:

C-M : outputs the sound of the CD
from the left, and the sound of the
microphone(s) from the right.
 M-C : outputs the sound of the
microphone(s) from the left, and
the CD sound from the right.
 OFF : outputs stereo mixed sound of
CD and microphone(s) from left
and right.
Using built-in effects
The effector of the CD-VT1MKII
consists of an effect library and a voice
change function.
Effect Library
There are 18 built-in preset effects.
You can adjust the parameters for each
of them.
Voice Change function
The Voice Change function allows
you to raise or lower the pitch of the
sound input from the microphone(s)
by 1 octave.
Using the effector
1. Switch the EFFECT ON/OFF
switch to ON.
2. Press the EFFECT key to open the
Effect menu.
3. Select EFF using either the PREV or
NEXT key.
4. Use either the UP or DOWN key to
select the preset effect (01-18).
5. Select PAR by pressing either the
PREV or NEXT key, then press ei-
ther the UP or DOWN key to set
the effect parameters (effect val-
ues).
6. Press the TIME/ESC key to exit
the Effect menu. The parameters
you have selected are automati-
cally stored.
Using the voice change
1. Switch the EFFECT ON/OFF
switch to ON.
2. Press the V.CHANGE key to open
the voice change menu.
3. Press either the UP or DOWN key
to select from the following:
 UP : raises the pitch of the sound
from the microphone by 1 octave
 OFF : the sound from the micro-
phone is not affected
 DN : lowers the pitch of the sound
from the microphone by 1 octave
4. Press the TIME/ESC key to exit
the voice change menu.
Using built-in effects
