Printing 3
User Manual 3-9
Margins and print area
When the printer places an image on paper, the image is a bit smaller than
the paper size. You may need to adjust the page margins in your application
software to match the print area.
Perforated paper and transparencies
Use Tektronix perforated paper or transparencies and the Tektronix
Phaser 240 driver to get the largest image areas. With Tektronix perforated
paper or transparencies, you can print the largest area and tear off the excess
at the perforation. This gives full A or A-4 Letter-size images within ISO
margins.
This illustration shows the largest image areas for perforated paper and
transparencies. All margins are 5 mm (0.2 in.). The bottom margin is
5 mm (0.2 in.) after the perforated area is removed.
1. American A-size (LETTER PERF)
2. Metric A4-size (A4 PERF)
1
9238-20
2
210 x 313 mm 8.5 x 12.3 in.
200 mm
287 mm
8.1 in.
10.6 in.
