10. SPECIFICATIONS
Power supply
Power consumption
Pick-up system
Image sensor
Scanning System
Video output pixels
Pixel clock frequency
Sync signal frequency
Sync system
Sensitivity
Minimum illumination
Lens mount
Ambient temperature
Ambient humidity
Weight
External dimension
White balance
Gain
Partial scanning
Output signal
Sync signal output
External sync input
External trigger input
Partial scanning control
signal input
Interface
Optional parts
12V DC±10%
Approx. 6.1W
RGB, 3CCD
1/3inch All pixels CCD
(Effective pixels Horizontal : 659, Vertical : 494)
Progressive scan
Horizontal pixels : 659, Vertical : 494
24.5454MHz
Horizotal : 31.469KHz, Vertical : 59.94Hz
Internal/External (Automatic switching)
F6.8 standard (2000 lx, 3000K)
14 lx (F2.2, Sensitivity + 18 dB, 3000K)
C mount (flange back : 17.526 mm in-air)
0 to 40°C (32 to 104°F)
Less than 90%
Approx. 160g (0.353lbs)
44 (W) x 44 (H) x 78 (D) mm
(1.73” (W) x 1.73” (H) x 3.07” (D)) (except for protruded portion)
AWB (Automatic white balance), MANUAL (Manual)
MANUAL (Manual), OFF (0 dB)
90fps, 115fps, 120fps, 160fps, 180fps, 240fps
8-bit RGB, Digital output (Camera Link format)
FVAL, LVAL, DVAL (Positive polarity)
Pixel Clock
HD : CC3 (LVDS input) Negative polarity
VD : CC4 (LVDS input) Negative polarity
CC1 (LVDS input), More than 2 µ s pulse width
CC2 (LVDS input)
Serial data interface : Ser TC (RXD), Ser TFG (TXD)
IK-TF5H (CAMERA HEAD) EXC-CL05S (Cable), etc
The designs and specifications are subject to change without notice.
