-- SHUTTER --

MODE

E.TRG

PW SNR

TRG.P
PART

OFF

• Partial scanning switch
OFF/90fps/115fps/120fps/160fps/180fps/240fps/
E90fps/E115fps/E120fps/E160fps/E180fps/E240fps

Input trigger pulse : positive polarity
Input trigger pulse : negative polarity

• E.TRG mode

1P SNR, 1P SR, PW SNR, PW SR, RR

• Input trigger pulse setting at PW SNR and PW SR

• Sutter mode MANU, SS, E.TRG

Move up down
by pushing
MENU UP, DOWN

Select the desired
value by pushing
DATA UP, DOWN

(1. 3. 3)

Changing the setting in PW SNR mode

(a) Changing the polarity of inputting trigger pulse setting

Move the "

→

" to TRG.P by pushing [MENU UP], [MENU DOWN] buttons.

Select either

by pushing [DATA UP], [DATA DOWN] buttons.

(b) Changing the partial scanning setting

Move the "

→

" to PART by pushing [MENU UP], [MENU DOWN] buttons.

Select the mode by pushing [DATA UP], [DATA DOWN] buttons.

Note:

The longer the storage time with extended exposures, the more visible certain characteristics of CCD
cameras become: fixed pattern noise, white pixels, etc.
