Trane RT-DS-10 - Manual (Page 44)

Library Product Literature
Product Section Unitary
Product Rooftop
Model 000
Literature Type Data Sales Catalog
Sequence 10
Date April 1999
File No. PL-UN-RT-000-DS-10-499
Supersedes RT-DS-10 12/94
Ordering No. RT-DS-10
The Trane Company
International Unitary Systems Group
3600 Pammel Creek Road
La Crosse, WI 54601-7599
www.trane.com
An American Standard Company
Since The Trane Company has a policy of continuous
product improvement, it reserves the right to change
design and specification without notice.
Tracer ® Originated Data
•
Command operating mode
•
Host controllable functions:
Supply fan
Economizer
Cooling stages enabled
Heating stages enabled
Emergency shutdown
•
Minimum damper position
•
Heating setpoint
•
Cooling setpoint
•
Supply air tempering enable/disable
•
Slave mode (CV only)
•
Tracer/local operation
•
SAT setpoint
•
Reset setpoint
•
Reset amount
•
MWU setpoint
•
MWU enable/disable
•
SAT reset type select
•
Static pressure setpoint
•
Static pressure deadband
•
Daytime warm-up enable/disable
•
Power exhaust setpoint
Zone Sensors
Shall be provided to interface with the
Micro unit controls and shall be
available in either manual, automatic
programmable with night setback, with
system malfunction lights or remote
sensor options.
Conventional Thermostat Interface
(CTI)
This field installed circuit board shall
provide interface with
electromechanical thermostats or
automation systems. Not available with
VAV system control.
Differential Pressure Switches
This field installed option allows
individual fan failure and dirty filter
indication. The fan failure switch will
disable all unit functions and “flash”
the Service LED on the zone sensor.
The dirty filter switch will light the
Service LED on the zone sensor and
will allow continued unit operation.
Electronic Time Clock
This field installed accessory kit will
allow the unit to operate in the
unoccupied mode or perform night set
up/set back functions utilizing a
standard individual scheduling.
Remote Potentiometer
A remote potentiometer shall be
available to remotely adjust the unit
economizer minimum position.
High Temperature Thermostats
Field installed, manually resettable high
temperature thermostats shall provide
input to the unit controls to shut down
the system if the temperature sensed at
the return is 135°F (57°C) or at the
discharge 240°F (115°C).
Reference Enthalpy Kit
Field installed enthalpy kit shall provide
inputs for economizer control based
upon comparison of the outside air
stream to a definable enthalpy
reference point. May also be factory
installed.
Comparative Enthalpy Kit
Field installed enthalpy kit shall provide
inputs for economizer control based
upon comparison of the enthalpies of
the return and outdoor air streams.
Also available factory installed.
LP Conversion Kit
Field installed conversion kit shall
provide orifice(s) for simplified
conversion to liquefied propane gas.
No change of gas valve shall be
required.
BAYSENS006* – Zone sensor has one
temperature setpoint lever, heat, off or
cool system switch, fan auto or fan on
switch. Manual changeover. These
sensors are for CV units only.
BAYSENS008* – Zone sensor has two
temperature setpoint levers, heat, auto,
off, or cool system switch, fan auto or
fan on switch. Auto changeover. These
sensors are used with CV units.
BAYSENS010* – Zone sensor has two
temperature set point levers, heat,
auto, off, or cool system switch, fan
auto or fan on switch. Status indication
LED lights, System on, Heat, Cool, and
Service are provided. These sensors
are used with CV units.
BAYSENS013* – Zone temperature
sensor with timed override buttons
used with Tracer ® Integrated Comfort
system.
BAYSENS014* – Zone temperature
sensor with local temperature
adjustment control and timed override
buttons used with Tracer Integrated
Comfort system. May also be used for
Morning Warm-up setpoint and sensor.
BAYSENS016* – Temperature sensor is
a bullet or pencil type sensor that could
be used for temperature input such as
return air duct temperature.
BAYSENS017* – Remote sensor can be
used for remote zone temperature
sensing capabilities when zone sensors
are used as remote panels or as a
morning warm-up sensor for use with
VAV units or as a zone sensor with
Tracer Integrated Comfort system.
BAYSENS019* and BAYSENS020* –
Electronic programmable sensors with
auto or manual changeover with seven
day programming. Keyboard selection
of heat, cool, auto fan or on. All
programmable sensors have System
on, Heat, Cool, Service LED/LCD
indicators as standard. Night setback
sensors have two occupied, and two
unoccupied programs per day. Sensors
are available for CV zone temperature
control and VAV zone temperature
control.
BAYSENS021* – Zone sensor with
supply air single temperature setpoint
and AUTO/OFF system switch. Status
indication LED lights, System ON, Heat,
Cool, and Service are provided.
Sensors are available to be used with
VAV units.
BAYSENS022* – Sensor is an
electronic digital zone sensor that can
be used as a Heat Auto/Cool
thermostat. The sensor has a large,
easily read continuous digital display of
the space temperature with setpoint
temperature displayed at the touch of a
button.
BAYSTAT023* – Remote Minimum
Position Potentiometer is used to
remotely specify the minimum
economizer position.
