Table 11-1 General Data 29-33 Tons
TC*350 (29 Tons)
TC*400 (33 Tons)
Cooling Performance
1
Nominal Gross Capacity(Btuh)
375,000 (105 kW)
409,000 (120 kW)
System Power kW
34.0
42.5
Compressor
Number/Type
2/Scroll
3/Scroll
Nominal Motor HP (ea)
12.5
Motor RPM
2875
2875
Natural Gas Heat
2
Low
High
Low
High
Heating Input (Btuh)
290,000 (85.0 kW)
500,000 (147 kW)
335,000 (98.2 kW)
670,000 (196 kW)
First Stage
250,000 (73.3 kW)
425,000 (125 kW)
300,000 (87.9 kW)
600,000 (176 kW)
Heating Output(Btuh)
243,000 (69.0 kW)
405,000 (119 kW)
271,350 (80.0 kW)
542,700 (159 kW)
First Stage
202,500 (59.4 kW)
344,250 (101 kW)
243,500 (71.4 kW)
486,000 (166 kW)
Steady State Efficiency(%)
3
81
81
No. Burners/No. Stages
1/2
1/2
Gas Connect Pipe Size (in)
0.75 (19 mm)
0.75 (19 mm)
Outdoor Coil - Type
LANCED
LANCED
Tube Size OD (in)
0.375 (10 mm)
0.375 (10 mm)
Face Area (sq ft)
51.3 (4.8 sq m)
69.8 (6.5 sq m)
Rows/Fins Per Inch (25mm)
2/16
2/16
Indoor Coil - Type
HI-PERFORM
HI-PERFORM
Tube Size (in) OD
0.500 (13 mm)
0.500 (13 mm)
Face Area (sq ft)
31.7 (2.9 sq m)
37.5 (3.5 sq m)
Rows/Fins Per Inch (25mm)
2/15
2/14
Refrigerant Control
TXV
TXV
PVC Drain Connect No./Size (in)
1/1.25 (1/32 mm)
1/1.25 (1/32 mm)
Outdoor Fan Type
PROP FAN
PROP FAN
No. Used
3
4
Diameter (in.)
28.0 (711 mm)
28.0 (711 mm)
Drive Type/No. Speeds
DIRECT/1
DIRECT/1
Cfm
20,400 (9650 L/s)
26,200 (12,400 L/s)
No. Motors (RPM)
3 (940)
4 (940)
Motor HP
0.75 (0.56 kW)
0.75 (0.56 kW)
Indoor Fan Type/No. Used
FC/1
FC/1
Diameter (in)
22.4 (568 mm)
25.0 (635 mm)
Width (in)
22.0 (559 mm)
25.0 (635 mm)
Drive Type
BELT
BELT
No. Speeds/No. Motors
1/1
1/1
Motor HP
7.5 (5.6 kW)
10.0 (7.5 kW)
Motor RPM/Frame Size
1460/213T
1460/215T
Filters - Type
THROWAWAY
THROWAWAY
Furnished/No.
Yes/16
Yes/17
Recommended Size (in)
16x20x2 (406x508x51mm)
16X 20 X2 (406X 508 X51mm)
Refrigerant Type
R-22
R-22
Factory Charge Ciruit #1 (lbs)
4
52 (24 kg)
24.5 (11.1 kg)
Factory Charge Circuit # 2 (lbs)
42.5 (19.3 kg)
Notes:
1. Cooling Performance is rated at 95°F (35°C) ambient, 80°F (27°C) entering dry bulb, 67°F (19°C) entering wet bulb. Gross capacity does not include the effect of
fan motor heat.
2. Heating Performance Limit settings and ratings data were established and approved under laboratory test conditions using American National Standards.
3. Steady State Efficiency is rated in accordance with DOE test procedures.
4. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
