Performance
Data
Table 29-2 – Power Exhaust Fan
Performance - 50 Hz English
External Static Pressure
– Inches of Water
Exhaust High Med Low
Airflow Speed Speed Speed
(Cfm) ESP ESP ESP
1000 0.800 – –
1500 0.780 – –
2000 0.750 – 0.400
2500 0.720 – 0.380
3000 0.680 – 0.370
3500 0.650 0.420 0.360
4000 0.610 0.380 0.340
4500 0.560 0.360 0.320
5000 0.520 0.330 0.300
5500 0.460 0.310 0.280
6000 0.420 0.290 0.250
6500 0.360 0.270 0.230
7000 0.310 0.240 0.190
7500 0.250 0.200 0.150
8000 0.200 0.160 0.120
8500 0.150 0.120 0.070
9000 0.100 0.060 0.000
9500 0.040 0.000 –
10000 0.000 – –
Table 29-1 – Supply Air Fan Drive Selections
5 HP 7.5 HP 10 HP 15 HP
Nominal Drive Drive Drive Drive
Tons (kW) RPM No RPM No RPM No RPM No
458 A
500 B
23 (80) 541 C
583 583 D
625 625* E
458 A
500 B
25 (88) 541 C
583 583 D
625 625 E
500 B
541 541 C
29 (103) 583 583 D
658 658** F
664 664* G
417 417 H
437 437 J
479 479 K
33 (118) 521 521 L
562 562 M
604 604 N
437 437 J
479 479 K
42 (146) 521 521 L
562 562 M
604 604 N
Note:
*For YC gas/electrics only.
**For TC and TE Cooling only and with electric Heat units only.
Notes:
1. Performance in table is with both motors operating.
2. High speed = both motors on high speed. Medium speed is one motor on high speed and one on low
speed. Low speed is both motors on low speed.
3. Power Exhaust option is not to be applied on systems that have more return air static pressure drop
than the maximum shown in the table for each motor speed tap.
Table 29-3 – Power Exhaust Fan
Performance - 50 Hz Metric
External Static Pressure
– Pa
Exhaust High Med Low
Airflow Speed Speed Speed
(L/s) ESP ESP ESP
470 199.3 – –
710 194.3 – –
940 186.8 – 99.6
1180 179.4 – 94.7
1420 169.4 – 92.2
1650 161.9 104.6 89.7
1890 152.0 94.7 84.7
2120 139.5 89.7 79.7
2360 129.5 82.2 74.7
2600 114.6 77.2 69.7
2830 104.6 72.2 62.3
3070 89.7 67.3 57.3
3300 77.2 59.8 47.3
3540 62.3 49.8 37.4
3780 49.8 39.9 29.9
4010 37.4 29.9 17.4
4250 24.9 14.9 0.0
4480 10.0 0.0 –
4720 0.0 – –
