Performance data – Trane RT-DS-10 User Manual
Page 23
23
Performance
Data
Table 23-1 Electric Heat Air Temperature Rise (Degrees F)
English
Heater
Total
CFM
Input (kW) MBh 7000 8000 9000 10000 11000 12000 13000 14000 15000 16000 17000
26.9
92
12.1
10.6
9.4
8.5
7.7
7.1
40.4
138
18.2
15.9
14.1
12.7
11.6
10.6
9.8
9.1
8.5
7.9
7.5
53.8
184
24.2
21.2
18.8
16.9
15.4
14.1
13.0
12.1
11.3
10.6
10.0
67.3
230
30.2
26.5
23.5
21.2
19.2
17.6
16.3
15.1
14.1
13.2
12.5
80.7
276
25.4
23.1
21.2
19.5
18.1
16.9
15.9
14.9
Notes:
1. Air temperature rise = (kW x 3413)/(scfm x 1.085).
2. All heaters on constant volume units provide 2 increments of capacity.
3. Air temperature rise in this table are based on heater operating at 415 volts.
Table 23-2 Electric Heat Air Temperature Rise (Degrees Celsius)
Metric
Heater
L/s
Input (kW) 3300
3780
4250
4720
5190 5660
6140 6610
7080
7550
8020
26.9
6.8
5.9
5.3
4.7
4.3
4.0
40.4
10.2
8.9
7.9
7.1
6.5
5.9
5.5
5.1
4.8
4.5
4.2
53.8
13.6
11.9
10.5
9.5
8.6
7.9
7.3
6.8
6.3
5.9
5.6
67.3
17.0
14.8
13.2
11.9
10.8
9.9
9.1
8.5
7.9
7.4
7.0
80.7
14.2
13.0
11.9
11.0
10.2
9.5
8.9
8.4
Notes:
1. Air temperature rise in this table are based on heater operating at 415 volts.
2. All heaters on constant volume units provide 2 increments of capacity.
Table 23-4 Natural Gas Heating Capacities
Heat Input MBh (KW)
Heating Output MBh (KW) Air Temp. Rise,
Tons
Unit Model No.
(See Note 1)
(See Note 1)
F (C)
YCD/YCH275**L
22.9-29.2
YCD/YCH300**L
290,000 (85)
243,000 (69)
10-40 (-12.2 , 4.4)
YCD/YCH350**L
YCD/YCH275**H
22.9-29.2
YCD/YCH300**H
500,000 (147)
405,000 (119)
25-55 (-3.9 , 12.8)
YCD/YCH350**H
YCD/YCH400**L
33.3-42.7
YCD/YCH500**L
335,000 (98)
271,350 (80)
5-35 (-15 , 1.6)
YCD/YCH400**H
33.3-42.7
YCD/YCH500**H
670,000 (196)
542,700 (159)
20-50 (-6.7 , 10)
Note:
1. Total heating capacity.
Table 23-3 Available Electric Heat KW
Ranges
Nominal
Nominal Voltage (v)
Unit Size
Tons
380
415
22.9
23-56
27-67
25.0
23-56
27-67
29.2
23-56
27-67
33.3
34-68
40-81
42.7
34-68
40-81
Notes:
1. KW ranges in this table are based on heater
operating at nominal voltages 380 or 415.
