2

1. Introduction

Tripp Lite’s Extended-Run Single-Phase Battery Cabinets connect to SmartOnline 3-Phase UPS Systems to provide long-lasting

battery backup for data centers, telecommunications, networks, industrial facilities, security, emergency systems and other mission-

critical applications that require high capacity, high availability and extended runtime.
Features

Battery cabinets are available in voltages from 192 VDC through 240 VDC and capacities from 33 to 720 ampere-hours with

a constant power rating of up to 595 kW @ 15-minute rate.

Battery cabinets contain multiple 6 or 12 VDC batteries connected in series for higher voltages or in series-parallel for higher

voltages and capacities. Multiple battery cabinets may be connected in series for increased runtime.

Depending on the number of individual batteries contained, each battery cabinet will have 3 tiers with 8 to 10 individual

batteries (maximum) per tier.

The battery cabinet structure is rated up through Seismic Zone 4 applications in compliance with the Uniform Building Code.

Removable access panels facilitate periodic maintenance. There is a minimum of 6 inches of clearance above the individual

batteries for access to terminals.

Battery cabinet frame and rails are 10 gauge steel; exterior panels are 16 gauge steel. Baked powder coat finish provides chip

and corrosion resistance.

Battery cabinet is shipped bolted to pallet with a double layer of protective stretch wrap and integrated corner and top

protection.

Appropriate ventilation and convection cooling of the individual batteries is provided via ½-inch spacing between batteries.

Front and rear vents allow the free flow of warmer air out of the battery cabinet.

The internal battery series or series-parallel circuits are completely wired. The negative leg of each series string of batteries

terminates into an insulated terminal block.

An optional molded case circuit breaker is available for over-current protection. (The molded case circuit breaker can be

fitted with a UV relay, shunt trip and auxiliary contacts as additional options.)

User-supplied power output cables can be fed into the battery cabinet through built-in 8-inch conduit knockouts in the top or

sides of the cabinet (gland plate included). Shorting bars provide a positive landing power connection for parallel strings in a

single cabinet. All available power connection points are at the top of the cabinet, above the topmost tier of batteries.

For improved safety, higher power density and minimized maintenance, the cabinet systems use Valve-Regulated Lead-Acid

(VRLA) recombinant batteries. The electrolyte in these batteries is immobilized in either an absorbent mat separator or a

gelling medium, eliminating the spilling hazards and maintenance requirements of free liquid electrolyte. There is no need to

add water or measure specific gravity.

Because the batteries are recombinant cells that employ an oxygen recombination cycle, minimal gasses are emitted during

normal float charging. Each cell contains an individual valve which releases the gas products of overcharge and prevents

pressure build-up within the cell.

Select battery cabinets (“C” models) include an integrated battery charger.
