Model #: APSX750F
230V PowerVerter APS X Series Inverter/Charger - with Fast Auto-Transfer Switching
Highlights
12V DC or 230V AC input; 230V, 50 Hz output; 2 AC outlets
750 watts continuous, 1125 watts OverPower and 1500 watts DoubleBoost
inverter output (see specifications)
3-stage, selectable 5/20 amp, wet/dry cell battery charger
Faster Auto Transfer Switching option for battery backup/UPS operation
Reliability enhanced large-transformer design with protected DC terminals
Description
Tripp Lite's APSX750F DC-to-AC inverter with faster automatic line-to-battery transfer and integrated charging system serves as an extended run
UPS, a standalone power source or an automotive inverter. Supplies up to 750 watts of continuous 230V AC power to 2 AC outlets from any 12V
battery or automotive DC source. OverPower inverter output feature temporarily provides up to 150% of the continuous output for 1-60 minutes and
DoubleBoost inverter output feature delivers up to 200% of the continuous output for up to 10 seconds, providing the extra power needed to cold
start heavy-duty tools and motorized equipment. When AC cable is connected to a live wall socket, commercial power passes through to connected
equipment and the battery set is recharged via 3-stage, selectable 5/20 amp charging system. In UPS mode, the APS system responds to blackouts
and voltage fluctuations with a near instantaneous automatic transfer to battery-derived AC output. Includes a set of high current DC input terminals
for simple installation (user supplies batteries and cabling - see Owner's Manual for recommendations). Passes sine wave utility or generator power
during battery charging and UPS line power operation, plus efficient PWM sine wave AC output in inverter and UPS backup modes. Reliable large
transformer design, with frequency control powers resistive electronic loads or large inductive motors, compressors and other items with high current
needs on startup. Optional APSRM4 wired remote power switch with full status LEDs provides remote power inverter on/off switching and continuous
status information (APSRM4 sold separately). Supports an unlimited amount of runtime with any number of user-supplied batteries connected. Highly
adaptable to a variety of applications and site conditions with adjustable charger settings for wet/gel battery types and selectable line to battery
power transfer voltages.
Applications
Versatile inverter/charger system with auto-transfer switching serves as an automotive inverter for RVs, over-the-road trucking, conversion
vans and fleet service vehicles; a standalone alternative power source for off-grid, alternative energy or export applications and as an
uninterruptible power supply (UPS) for items compatible with a 10 millisecond transfer time.
Package Includes
APSX750F Inverter/Charger
Owner's Manual with warranty information
(1) IEC Universal Outlet Adapter
Features
APSX750 serves as an automotive or stationary DC-to-AC inverter with automatic line-to-battery transfer and integrated battery charger
Supports 230V AC output from a 230V AC line power source or 12V DC battery source
