background image

14

7.1 Dimensions and Floor Loading

7.2 Recommended Torque

7. Specifications

Battery Cabinet Model

Shelves

Dimensions

(Width x Depth x Height)

Weight

Floor Loading

BP240V557C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1250 lb

(567.5 kg)

193 lb/ft

2

(943 kg/m

2

)

BP240V787C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1850 lb

(840 kg)

285 lb/ft

2

(1395 kg/m

2

)

BP240V1037C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1983 lb

(900.3 kg)

306 lb/ft

2

(1496 kg/m

2

)

BP240V1407C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

2463 lb

(1118.2 kg)

380 lb/ft

2

(1857 kg/m

2

)

BP192V557C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1130 lb

(513 kg)

174 lb/ft

2

(852 kg/m

2

)

BP192V787C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1628 lb

(739.1 kg)

251 lb/ft

2

(1228 kg/m

2

)

BP192V1037C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1773 lb

(804.9 kg)

274 lb/ft

2

(1337 kg/m

2

)

BP192V1407C-1PH

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

2070 lb

(939.8 kg)

319 lb/ft

2

(1561 kg/m

2

)

BP192V557C-16K

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1130 lb

(513 kg)

174 lb/ft

2

(852 kg/m

2

)

BP192V787C-16K

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1628 lb

(739.1 kg)

251 lb/ft

2

(1228 kg/m

2

)

BP192V1037C-16K

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

1773 lb

(804.9 kg)

274 lb/ft

2

(1337 kg/m

2

)

BP192V1407C-16K

3

32.4 x 28.8 x 60 inches

(82.3 x 73.2 x 152.4 cm)

2070 lb

(939.8 kg)

319 lb/ft

2

(1561 kg/m

2

)

Battery Cabinet Model

Terminal Type

Torque

BP240V557C-1PH

10-32 Threaded Insert

25 in·lb (2.8 N·m)

BP240V787C-1PH

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP240V1037C-1PH

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP240V1407C-1PH

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP192V557C-1PH

10-32 Threaded Insert

25 in·lb (2.8 N·m)

BP192V787C-1PH

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP192V1037C-1PH

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP192V1407C-1PH

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP192V557C-16K

10-32 Threaded Insert

25 in·lb (2.8 N·m)

BP192V787C-16K

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP192V1037C-16K

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)

BP192V1407C-16K

1/4-20 Threaded Insert

110 in·lb (12.4 N·m)
