74
Super I/O configuration submenu
ACPI settings submenu
Use this screen to change options for ACPI. Use the up and
down keys to select an item. Use the and
keys to change the value of the selected option. A
description of the selected item appears on the right side of
the screen.
Feature Option Description
Win627 Super I/O Chipset
Onboard
floppy con-
troller Enabled
Disabled Enables or disables the onboard floppy
controller
Serial Port 1
Address 3F8/IRQ4
3E8/IRQ4
2E8/IRQ3
Disabled Sets the serial port 1 (com 1) base I/O
address and an interrupt number. Dis-
abled - port disabled
Serial Port 2
Address 3F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled Sets the serial port 2 (com 2) base I/O
address and interrupt number. Disabled -
port disabled
Serial Port 2
Mode Normal
IrDA
ASK IR Allows BIOS to Select Mode for serial
port 2
Parallel port
address 378
278
3BC
DIsabled Assigns the Parallel Port I/O address.
Disabled - Port disabled
Parallel Port
Mode Bi-Directional
Normal
EPP
ECP Configures parallel port mode.
Bi-directional - send and receive data.
Normal - can send data.
EPP - Enhanced parallel port.
ECP - Extended capability port.
Parallel Port
Interrupt IRQ7
IRQ5 Assigns IRQ to parallel port
