ITEM DESCRIPTION
PART NUMBER
FIGURE NUMBER (PAGES 65-78)
Nut, Flange, 1/4-20
100906
38
Nut, M5, Yellow Zinc (Magnetrons, Bottom Electrical Plate)
100101
None
Nut, Push, 1/8
101293
35
Nut, Stainless, #4-40
102960
17
Pad, Abrasive, Non-Slip
NGC-1187
46, 47
Pin, Clevis, 3/16 Diameter x 1” Long
101119
30
Plate, Door Switch
NGC-1126
30, 31, 33, 34
Plug, Hole, Black, 1/2” Diameter
101191
46, 47
Rack, Raised
NGC-3064
46, 47
Rack, Recessed
NGC-1274
46
Rack, Standard
NGC-1064-1
46
Reader, Smart Card
100506
17
Relay, K1, Filament Transformers
101273
20
Relay, K2, HV Transformers
101273
20
Relay, K3, Monitor
101273
20
Relay, K4/K5, Solid State, Convection Heater/IR Element
NGC-3005
38
Relay, K6, 208/240 Transformer Taps (USA only)
101272
None
Relay, K7, Magnetron Fan, DNK
NGC-3030-11
None
Relay, K7, Magnetron Fan, OXXO
NGC-3030-5
None
Relay, K7, Magnetron Fan, SBK (USA)
NGC-3030-3
20
Relay, K7, Magnetron Fan, SBK (Europe, Asia-Pacific MPh)
NGC-3030-15
20
Relay, K7, Magnetron Fan, SBK (Europe SPh)
NGC-3030-13
20
Relay, K7, Magnetron Fan, SBK (Indiana/North Carolina)
NGC-3030-14
20
Relay, K7, Magnetron Fan, Standard (USA)
NGC-3030-1
20
Relay, K7, Magnetron Fan, Standard (Europe, Asia-Pacific MPh)
NGC-3030-4
20
Relay, K7, Magnetron Fan, Standard (Europe SPh)
NGC-3030-7
20
Relay, K7, Magnetron Fan, Standard (Latin America)
NGC-3030-12
20
Relay, K7, Magnetron Fan, SWY (USA)
NGC-3030-2
20
Relay, K7, Magnetron Fan, SWY (Europe, Asia-Pacific MPh)
NGC-3030-9
20
Relay, K7, Magnetron Fan, SWY (Europe, Latin America SPh)
NGC-3030-6
20
Relay, K7, Magnetron Fan, TESCO
NGC-3030-10
None
Relay, K7, Magnetron Fan, WAWA
NGC-3030-8
None
Ring, E-clip
101296
30
Ring, Snap
101312
39
Screw, #4-40 x 5/8
102902
31
Screw, #4-40 x 3/4
101555
32
Screw, #4-40 x 1 1/8
101558
33, 34
Screw, #4-40 x 1 1/4
101557
29, 30
Screw, #6, Sheet Metal
100684
21
Screw, #8, Crescent, TRHD, Serrated Phillips
101688
35, 38, 39, 46
Screw, #8, Crescent, TRHD, Serrated Phillips, Black Oxide
101691
47
Screw, #8-16, Torx Security
102752
46
Screw, #8-16 x 1/2, Torx Security, Black Oxide
102756
47
Screw, #8-18, SS
101701
22
Screw, #8-32 x 3/8
102921
29, 30, 31, 32, 33, 34, 46
Screw, #8-32 x 3/8, PFH, CSK
102809
22, 26, 29, 32, 35
Screw, #8-32 x 3/8, PPHD, SEM, SS, Internal Tooth
102922
47
Screw, #8-32 x 3/8, Torx Security
102748
35
Screw, #8-32 x 1/2, Cap
101666
22
Screw, #10-32 x 1/2, SS, Hex
101381
26
Shield, Microwave
NGC-1116
39
