SERVICE PARTS AND ILLUSTRATIONS
75
Convection Circuit Parts
102. 101688
Screw, #8 x 1/2” PTH
103. NGC-1081 Cover, Motor
104. 100906
Nut, 1/4”-20, Flange
105. NGC-1025 Assy, Blower Motor
106. NGC-3007 Kit, Fan Blade
107. NGC-1024 Sealing Block, Blower
108. NGC-1023 Clamp, Blower Seal
109. 101688
Screw, #8 x 1/2” PTH
110. NGC-3011 Heater, Convection
111. 100443
Controller, Motor
112. NGC-3005 Relay, K4/K5 SSR
113. 100592
Fuses, F1 and F2 (12 Amp)
114. 102075
High-Limit Thermostat
115. NGC-1043 Gasket, Convection Heater
* If entire motor is needed, order NGC-1025.
If only hardware (screws, nuts) or seal is needed,
contact 800.90
TURBO
or +1 214-379-6000.
** Not shown for clarity.
FIGURE 38: CONVECTION CIRCUIT ASSEMBLY AND PARTS
Chapter 7: Convection Circuit - Page 48
NO
TICE:
This devic
e c
omplies with P
art 18 of the FC
C Rules
.
Oper
ation i
s subj
ect t
o the f
ollo
wing c
onditions:
1. Th
is devic
e ma
y not cause harmful in
terfe
renc
e.
WARNING:
DHHS F
eder
al P
erfo
rmanc
e Standar
d 21 CFR 1030.10.
To pr
ovide c
ontinued pr
otec
tion against elec
trical
Pour assur
er pr
otec
tion c
ontinue c
ontr
e le cho
c
shock,
connec
t to pr
operly gr
ounded outlets only
.
AVERTI
SSEMENT
:
corre
ctem
ent mise a t
err
e.
elec
trique br
anche
z seulement a un
e prise
undesir
ed oper
ation.
2. Th
is devic
e must acc
ept an
y int
erfe
renc
e
rece
ived
, including in
terfe
renc
e that ma
y cause
This O
ven c
omplies with applic
able sec
tions of
111
x6
113
112
102
103
104
105
109
110
114
x8
x10
108
107
*
*
*
**
106
