TurboChef Technologies, Inc. C Series
7-19
C3/C AND C3/CMULTI DOOR ASSEMBLY PARTS: See Figure 4-8
Item Part
Number
Description Used on Model(s)
1 C0190 SHUNT, DOOR C3/C & C3/CMULTI
2 C0325 SEAL, ENVIRONMENTAL C3/C & C3/CMULTI
3 C0427 SHUNT, SUPPORT, SHIM C3/C & C3/CMULTI
4 N/A SCREW, M4 X 12 MM SS C3/C & C3/CMULTI
5 C0254 COVER, DOOR PLASTIC C3/C & C3/CMULTI
6 C0426 SHUNT SUPPORT DOOR C3/C & C3/CMULTI
7 N/A WAHSER, M4 SS C3/C & C3/CMULTI
8 N/A WASHER, LOCK, M4 SS C3/C & C3/CMULTI
9 N/A NUT M4 SS C3/C & C3/CMULTI
10 C0575 DOOR INSULATION C3/C & C3/CMULTI
11 C0431 DOOR INSULATION C3/C & C3/CMULTI
12 C0267 HANDLE COOK CHAMBER C3/C & C3/CMULTI
13 N/A SCREW, M4 X 12 MM SS C3/C & C3/CMULTI
14 C0350 SPACER, DOOR HANDLE C3/C & C3/CMULTI
15 C0500 ASSY, ARM RH C3/C & C3/CMULTI
16 N/A WASHER, M4 SS C3/C & C3/CMULTI
17 N/A WASHER, LOCK M6 SS C3/C & C3/CMULTI
18 N/A BOLT, M6 X 20 MM SS C3/C & C3/CMULTI
19 C0550 ASSY, ARM, LH C3/C & C3/CMULTI
20 C0503 ASSY, PIN C3/C & C3/CMULTI
21 C0504 WASHER, NYLON C3/C & C3/CMULTI
