background image

TurboChef Technologies, Inc. C Series

6-6

ELECTRICAL COMPONENTS PARTS LIST SUMMARY

Item #

Part

Number

Description

Used on Model(s)

1

T0322

Circuit Breaker CB1-35A w/Trip Coil

C3/AB & C3/C

2

100596

12 Amp Aux Fuse

All

2b

100597

25 Amp Heater Fuse

C3/C

2c

100591

Fuse Holders

All

3

R7603

Convection High Limit

C3/AB & C3/C

3

102016

Convection High Limit

C3Multi & C3/CMulti

4

M9608

24 VDC Power Supply

All

6

T0278 &

T0309

Relay (24 VDC Coil/240 VAC Output) &

Socket

All

7

101285

Solid State Relay for Heater

All

8

101285

Solid Sate Relay for Magnetron

All

9

T0265

SMT Controller

All

10

M9609

Electrical Compartment Cooling Fan

C3/AB & C3Multi

10

100519

EBM Electrical Compartment Cooling Fan

C3/C & C3/CMulti

11

T0262

Magnetron Cooling Fan

All

12

101891

Stirrer Motor

All

13

100480

HV Diode

All

14

100206

HV, Capacitor, 2500 V

All

15

102091

Filament Transformer

All

16

102093

Magnetron Transformer T1

All

17

100860

Magnetron

All

18

100441

Blower Motor Speed Controller

All

ELECTRICAL COMPONENTS PARTS LIST (CON’T): All C Series Ovens-
