Commander Installation Guide
Page 74 of 81 Trilogy Communications Limited Issue 9
8.5.4.4 500-3x-3x Series Expansion panel interconnection cables
Type A (max. length 10 metre)
D9 Free Plug -
Pin Function Function D9 Free Plug -
Pin
4 Transputer
Data out + Pair 1 Transputer
Data in + 4
8 Transputer
Data out - Transputer
Data in - 8
5 Transputer
Data In +
Pair 2 Transputer
Data out + 5
9 Transputer
Data In -
Transputer
Data out - 9
3 Ground Ground 3
Type B (max length 10 metres)
D9 Free Plug -
Pin Function Function D9 Free Plug -
Pin
4 Transputer
Data out + Pair 1 Transputer
Data in + 5
8 Transputer
Data out - Transputer
Data in - 9
5 Transputer
Data In +
Pair 2 Transputer
Data out + 4
9 Transputer
Data In -
Transputer
Data out - 8
3 Ground Ground 3
8.5.5 CONNECTING VIA STRUCTURED CABLING
All control panel types may be connected to the matrix by Category 5 structured cabling
systems. Suitable adaptors are available from most electronic component distributors. The
RS part numbers are listed below.
Panel Connection: RJ45 to D9 socket. RS 818-700
Matrix Connection: RJ45 to D9 plug. RS 818-693
As supplied, these adaptors require the pins to be inserted into the D type housing. Use the
following table as a guide. The colour codes may not be correct for other brands.
D9 pin RJ 45 pin Colour (see above)
1 No connection No connection
2 2 Yellow
3 6 Brown
4 4 Red
5 8 Blue
6 1 Black
7 3 Orange
8 5 Green
9 7 Grey
