Commander Installation Guide
Page
26
of
81
Issue 9
Trilogy Communications Limited
Miscellaneous I/O Card Output Connections
Commander D25 Fixed Socket
Pins
Upper Connector
Description
1 Ground
2/14 Output
1
3/15 Output
2
4/16 Output
3
5/17 Output
4
6/18 Output
5
7/19 Output
6
8/20 Output
7
9/21 Output
8
10/22 Output
9
11/23 Output
10
12/24 Output
11
13/25 Output
12
Commander D25 Fixed Socket
Pins
Lower Connector
Description
1 Ground
2/14 Output
13
3/15 Output
14
4/16 Output
15
5/17 Output
16
6/18 Output
17
7/19 Output
18
8/20 Output
19
9/21 Output
20
10/22 Output
21
11/23 Output
22
12/24 Output
23
13/25 Output
24
Typical external circuitry for the logic outputs is given on Page 28.
Miscellaneous I/O Card RS422/Monitoring Connections
Commander D9 Fixed Socket
Pin
Description
1 Ground
2 RS422
Out-
3 RS422
In-
4
Audio Monitor Out-
5 Not
Used
6
RS422 Out+ OR RS232 Out
7
RS422 In+ OR RS232 In
8
Audio Monitor Out+
9 Not
Used
Further information is available in the 500-10 Technical Manual, which is available on
request from Trilogy Communications.
