5.2 PART REPLACEMENTS
The following sections describe the requirements for removing both major assemblies and,
where applicable, components on those assemblies that appear in the list of spares. Only
removal descriptions appear. Unless noted otherwise, replacements can take place by reversing
the steps required for removals. Also, replacements for some items in the spares list do not
appear. These items are considered too easily identifiable to warrant descriptions.
5.2.1 Rear Case Removal
Figure 5-1 shows the fasteners holding the Rear Case member. Proceed as follows:
Step 1. Remove the four screws shown.
Step 2. Open the Cover, remove the Rear Case.
980264-001 Rev. B
5-3
CHAPTER 5
Figure 5-1. Rear Case Fasteners.
