980264-001 Rev. B
3-9
CHAPTER 3
C a r d Fe e d
R o l l e r
Cleaning
Roller
Transport
and Platen
Rollers
Ribbon
Take Up
Card
Path
Daughter
Board
Magnetic
Encoder
(Option)
Cam Follower
(Raises Encoder Station Pinch Roller)
Smart Card
Station
(Option)
Head Up/Down
Sensors
Card
Sensor
Print Head
Latched Sensor
Flag
Sensor
Ribbon
Sensor
Print Head
Card Input
Hopper
To Card
Catcher
To Card
Catcher
Figure 3-1. Card Path Elements.
