Port Based VLAN
Having selected Port Based VLAN in the VLAN Configure menu, the next task is to create
and assign ports into the VLAN. This is achieved by selecting ‘Create VLAN Group’ from the
main VLAN Configuration menu. The following information is required:
• VLAN Name
• VLAN Group ID
• VLAN Port Membership
VLAN Name
This is a local value intended to provide a simple description of the VLAN, such as Sales,
Accounts etc.
VLAN Group ID
This is used to provide a number identifier for the specific VLAN. The legal range is 1 to 4094,
with 1 being the default value. The VLAN Group ID must be a unique number for each VLAN.
VLAN Port Membership
To assign ports to a VLAN use the key to scroll through the port list and then the
to toggle the membership status between No and Member. Select page> and from the action line to see further ports in the list. Select the required
ports to be members of this VLAN and then use to move to the action line and then
the settings.
