Setting Description
Screen Blanker Allows you to determine if the Screen Blanker feature is turned on, and the time frame it is set
for. When selected, a highlight bar will appear at the bottom of the OSD, allowing you to enter
a time frame from 0 to 30 minutes. If there is no console activity for the amount of time set
here, the screen will be blanked. When blanked, console activity such as mouse movement
will bring the display back. A setting of 0 disables this feature. It is disabled by default.
HOTKEY COMMAND MODE This setting allows you to enable or disable hotkey functionality. When turned off, you will not
be able to access Hotkey Setting Mode to control the KVM. When accessed, a highlight bar
will appear at the bottom of the OSD Settings Page. Press
[Y] to turn the hotkey functionality
on, or [N] to turn it off. It is enabled by default.
HOTKEY Selects which command is used to activate Hotkey Setting Mode. When selected, a sub-menu
will appear, allowing you to choose between
[Num Lock], [-] and [Ctrl], [F12]. Highlight the
desired hotkey and press the [ Enter] key, or double-click on it with your mouse. The default
OSD hotkey is [Num Lock], [-].
OSD LANGUAGE Selects which language the OSD is displayed in. When selected, a sub-menu will appear,
allowing you to choose between English, German, Japanese, Traditional Chinese and
Simplified Chinese. Simply highlight the desired language and press the [ Enter] key or
double-click on it with the mouse. The language is set to English by default.
SET CONSOLE KEYBOARD Allows you to select the language of the keyboard that is connected to the KVM console
port, which helps to ensure that the correct keyboard input is sent through the KVM to the
connected computers. The default is AUTO.
SET LOGOUT TIMEOUT Allows you to set the amount of idle time that must pass before a user is logged out of the
KVM, requiring them to enter their username and password to regain access. When accessed,
a highlight bar appears at the bottom of the OSD, allowing you to enter a value between 0
and 180 minutes. This setting defaults at 0, which disables the Logout Timeout function.
ACTIVATE BEEPER Allows you to turn the beeper on or off. When activated, the beeper sounds when changing
ports, performing hotkey commands, activating an Auto Scan or when an invalid entry is made
in the OSD. This setting is turned on by default.
SET QUICK VIEW PORTS Allows you to set ports as Quick View ports. When selected, the port list will be displayed,
allowing you to select or unselect ports as Quick View ports by highlighting them and pressing
the
[Spacebar] key, or by double-clicking on them with the mouse. Setting ports as Quick
View ports lets you customize which ports are displayed in the OSD main screen (See F2:LIST
on page 14 for details) or accessed during Auto Scan and Skip modes. (See the Scan/Skip
Mode setting in the F3:SET menu section on page 14 for details) By default, there are no
ports selected as Quick View ports.
OSD Operation
