93
Note
One ZM-9001 or one ZM-9002 can
be connected to each of the REMT
VOL1 and 2 terminals.
REMT VOL1
(Remote volume 1)
REMT VOL2
(Remote volume 2)
IN
E
IN
E
OUT
ZM-9001
ZM-9002
1
2
3
4
Volume control
1
2
3
4
5
6
E
OUT
E
16.1.2. When the ZM-9001 or ZM-9002 is connected
IN
(Control inputs)
OUT
(Control outputs)
1
2
3
4
E
1
2
3
4
E
ZM-9003
To the C-001T module (Control input/output terminal)
4 interlocking switches
1
2
3
4
5
6
1
2
3
4
5
6
E
16.1.3. When the ZM-9003 is connected
Output terminal Nos. 1 – 4 of the ZM-9003 are internally connected to the interlocking switches and Nos. 5
and 6 to the momentary switches.
Connect these terminals to the Control input terminals of the main unit or C-001T depending on applications.
IN
(Control inputs)
OUT
(Control outputs)
1
2
3
4
E
1
2
3
4
E
SS-9001
ZONE 1
G
CTRL IN
ZONE 2
G
ZONE 3
G
ZONE 4
G
16.1.4. When the SS-9001 is connected
The control input terminals of SS-9001 are polarized non-voltage contact inputs. With the interlock output
terminal setting in the Event setting, the SS-9001's internal relays can be activated. Make necessary
connections depending on applications.
