48
E V E N T 0 1 I N 1
Input channel name
(B3) Input channel setting (when Event classification is set to ROUTE)
Set the input channel using the Input channel selection key.
The name of the set input channel is displayed on the screen.
One input channel can be set per Event.
E V E N T 0 1 N O N E
(B1) Event number selection
Event number
E V E N T 0 1 N O N E
(B2) Event classification setting
Event classification
• NONE: Invalidates the selected Event.
• ROUTE: Sets broadcast patterns consisting of input/output, trigger, and other settings.
• BGM END: Used to perform settings for terminating all Events to which inputs with priority 8 are assigned.
• BASE:
Groups broadcast patters which have been set to "Priority 8 Input with Trigger set to NONE " in
Classification ROUTE, so that they may be activated with a single trigger. This classification is
normally used to set the Event of BGM broadcasts.
Notes
• Screens that appear when the Up or Down shift key is pressed differ depending on the Event classification
settings.
• When the priority of input channel to be set in "ROUTE" is 8 (BGM Event), the BGM End setting and its
activation are required to terminate the BGM Event.
Events except the BGM Event are terminated in any of the following cases:
· If an Event is activated at the control input terminal or by the VOX function, this Event is terminated when
the activation trigger is turned off.
· If an Event is activated by the ZM-9001 or ZM-9002, this Event is terminated when the control input
terminal set for "BUSY-IN" is turned off.
· When Events with higher priority level override all output channels of the Event in progress, this forcibly
terminates the original Event.
13.6.2. Event setting items
Unless otherwise specified, use the Parameter setting knob for each parameter selection.
01 – 32 (default: 01) Setting Range
NONE (default), ROUTE, BGM END, BASE Setting Range
IN1 – 8 (default: IN1) Setting Range
