Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03
METASYS N2 application
Integra 1560/1580 Point Mapping table
Address
Parameter Description
Units
1
Voltage 1
Volts
2
Voltage 2
Volts
3
Voltage 3
Volts
4
Current 1
Amps
5
Current 2
Amps
6
Current 3
Amps
7
Voltage average
Volts
8
Current average
Amps
9
Power (Watts) Sum
kW
10
VA Sum
kVA
11
var Sum
kvar
12
Power Factor average
13
Frequency
Hz
14
Active Energy (Import)
kWh
15
Reactive Energy (Import)
kvarh
16
Watts Demand (Import)
kW
17
Maximum Watts Demand (Import)
kW
18
Amps Demand
Amps
19
Maximum Amps Demand
Amps
20
Voltage L1-L2 (calculated)
Volts
21
Voltage L2-L3 (calculated)
Volts
22
Voltage L3-L1 (calculated)
Volts
23
Neutral Current
Amps
24
Active Energy (Import)
GWh
25
Reactive Energy (Import)
Gvarh
The following parameters are available only on the Integra 1540
26
THD V1
%
27
THD V2
%
28
THD V3
%
29
THD I1
%
30
THD I2
%
31
THD I3
%
32
THD Vmean
%
33
THD Imean
%
