Contents Page
2.15 Demand 17
2.16 Maximum Demand 17
2.17 Over Range 17
2.18 kWh and kVArh Display Range 18
2.19 Error Messages 18
3 Setting up 18
3.1 Introduction 18
3.2 Number Entry Procedure 19
3.3 Access 21
3.3.1 Access with No Password Protection 21
3.3.2 Access with Password Protection 21
3.4 Changing the Password 23
3.5 Full Scale Current 24
3.6 Potential Transformer Primary Voltage 24
3.7 Potential Transformer Secondary Value 26
3.8 Demand Integration Time 27
3.9 Resets 28
3.10 Pulsed Output, Pulse Duration 29
3.11 Pulse Rate 30
3.12 RS485 Baud Rate 31
3.13 RS485 Parity Selection 32
3.14 RS485 Modbus Address 33
3.15 Analogue Output Set Up 34
3.15.1 Introduction 34
3.15.2 Analogue Output Scaling Example 35
3.15.3 Power Factor 36
3.15.4 Phase Angle 39
3.15.5 Parameters available for analogue outputs 40
3.15.6 Reading (Parameter Selection) - A1r or A2r 41
3.15.7 Reading Top – A1rt or A2rt 42
2 Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03
