4.3.15 Active Energy Pulsed Output Option

Rated

SPNO, 100V dc, 0.5A Max.

Default pulse rate

1 per kWhr

Pulse rate divisors

1
10 (yielding 1 pulse per 10 kWhr)
100 (yielding 1 pulse per 100 kWhr)

Pulse duration

60ms, 100ms or 200ms, 3600 Pulses per hour max

4.3.16 Integra 1540 Only

Measuring Range: Total Harmonic
Distortion:

Up to 15th Harmonic 0%-50%

Accuracy:

Total Harmonic Distortion 1%

Reference conditions of measurands:

Voltage: 60% to 100% of nominal for THD

Reference conditions of measurands:

Total Harmonic Distortion: 20% to 100% of nominal for THD

Reference conditions of measurands:

Total Harmonic Distortion: 0-30%
