Appendices Apx. C Pin Assignments
C-24 EQUIUM M40/M45/Sarellite M40/M45 Maintenance Manual
190 /M_DATA(63) I/O 191 /+V2.5 -
192 /+V2.5 - 193 /SB_SMDAT_3 I/O
194 /+V3S - 195 /SB_SMCLK_3 I/O
196 DGND - 197 /+V3S -
198 DGND - 199 DGND -
C.25 CN508 DDR DIMM0 Socket (200-Pin)
Table C-25 DDR DIMM0 Socket (200-Pin)(1/4)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 /N$496545 O 2 /N$496545 -
3 DGND - 4 DGND -
5 /M_DATA(0) I/O 6 /M_DATA(4) I/O
7 /M_DATA(1) I/O 8 /M_DATA(5) I/O
9 /+V2.5 - 10 /+V2.5 -
11 /M_DQS(0) O 12 /M_DM(0) O
13 /M_DATA(2) I/O 14 /M_DATA(6) I/O
15 DGND - 16 DGND -
17 /M_DATA(3) I/O 18 /M_DATA(7) I/O
19 /M_DATA(8) I/O 20 /M_DATA(12) I/O
21 /+V2.5 - 22 /+V2.5 -
23 /M_DATA(9) I/O 24 /M_DATA(13) I/O
25 /M_DQS(1) O 26 /M_DM(1) O
27 DGND - 28 DGND -
