The Grand Tour
LCD
Strata CIX IP5000-series Telephone UG 04/09
9
LCD
9-Line LCD Display
The LCD on the 9-Line LCD telephone (shown below) in idle state shows:
Top to Bottom
Line 1 or the top line of the LCD will display your user name (if programmed) and
your extension number.
Line 2 will show the Date and time.
Line 3 will show information related to your telephone set: VM New/Saved messages,
Call Forward, or if a certain feature is enabled on your telephone set.

A plus sign + on the LCD indicates there is more data to display. Press
NEXT
to
advance through the information.
Lines 4~8 will indicate Programmable Feature Button labels. See “Browser” on Page 10
Line 9 will display the Soft Keys (See “Soft Keys” on page 11 ).
Shift Button
toggles between
Programmable
Feature Buttons
1~10 and 11~20.
Navigation Button -
See
“Browser” on
Page 10
Blue Button – toggles in-
between call processing
screen and HTML
browser or programming.
