Hardware Connections
B
IP5000-Series Telephone Tilt Angles
The IP5000-series telephones have three tilt positions built into the base. There is also
a tilt stand extension that adds an additional 20 degrees of tilt. When the telephone is
sitting on a desk or table there are a total of six different angles of tilt available. When
wall mounted there are two angles available. See figures on the next page.
Table 26
IP5000-Series Tilt Angels
Model
Tilt Without Stand
Tilt with Stand
IP5000-series telephones
15°, 27.5°, 40°
35°, 47.5°, 60°
All Add-on and IDM modules
