Browser
AP Windows Client
1. Set the IP address of the computer/server
you are using to access the B051-000 to
192.168.0.XXX, where XXX represents
any number or numbers except 10.
(192.168.0.10 is the default IP address of
the B051-000)
2. Access the B051-000 by entering its
default IP address (192.168.0.10) into
your browser.
3. Once logged into the B051-000, you
can customize the Network Settings
by clicking on the Network Icon on the
B051-000 home page. Assign an IP
address for the B051-000 that is suitable
for the network segment that it resides on.
4. After you log out, reset your computer’s
IP address to its original value.
For computers running Windows, the B051-
000 IP address can be determined using the
Windows AP program. Run the Windows
Client AP Installer file from the CD that
came with the B051-000 and follow the
step-by-step instructions. The first time you
login to the AP Windows Client, you will
need the serial number located on the CD
that came with the B051-000. This is not
the same as the serial number on the bottom
of the unit. When you run the program it
searches the network segment for B051-000
devices, and displays the results in a dialog
box similar to the one to the right:
To update the network settings, you must
click on the Login button to log into the
B051-000. Once logged in, click on the
Admin Utility
button to access the B051-
000 Admin Utility. From there you can get
to the network settings screen by clicking
the Network
tab.
Browser Login
The B051-000 IP Remote Access Unit can be accessed from a browser or via the Windows
and/or Java application (AP) program. This Quick Start Guide shows you how to login
using your browser. For non-browser access, reference the Owner’s Manual on the CD.
