P RODUCT M ANUAL 433689-01
I NDEX
compatibility
with previous VXA generations 50
with software and operating systems 18
compliance, safety and regulatory 62 to 64
components, back panel
external SCSI model 4
internal tape drive 3
components, front panel 2
compression 50
connectors, back panel
external tape drive 4
internal tape drive 3
See also AC power connector
See also auxiliary connector
See also power connector
See also SCSI connectors
See also serial connector
cooling 59
D
data capacities 49
data transfer rate 50
DC voltages 54
device drivers 18
diagnostic port, location (external model) 4
diagnostics, performing 31 , 36
dimensions 52 to 53
Discrete Packet Format 50
door
loading a cartridge 22
location 2
drive bay, installing the SCSI tape drive 8 to 13
E
eject button
doesn’t eject cartridge 27
location 2
using to eject cartridge 22
enclosure, installing the SCSI tape drive 8 to 13
environmental specifications 56 to 60
error
LED indicators 20
reported in software 29 to 30
error detection and correction 50
error rate 50 to 51
error recovery procedures, for Service
Notification LEDs 28 to 29
ESD protection 10
Extended Messages (01h) message
Parallel Protocol Request (04h) 39
Synchronous Data Transfer Request
(01h) 39
Wide Data Transfer Request (03h) 39
external tape drive, installing the SCSI tape
drive 14 to 16
F
Fast-80 DT SCSI
See High-density (HD) SCSI
firmware, upgrading 36
form factor 52
format, read and write 50
front panel
See components, front panel
G
grounding hole and tab (internal model)
location 3
using to ground tape drive 10
H
heads, read/write 50
High-density (HD)
SCSI interface requirements 40 to 43
transfer rates 50
host bus adapter, Ultra160 SCSI 8 , 14
humidity, specifications
tape drive 56 to 58
VXAtape cartridges 60
I
ID switch
See SCSI ID switch
installing backup software 9 , 14
installing software 18
integrating the tape drive into a system 18
internal tape drive, installing 8 to 13
J
jumpers
