52
P RODUCT M ANUAL 433689-01
C
HAPTER
7 S
PECIFICATIONS
S
IZE AND
W
EIGHT
Table 7-6 shows the dimensions and width for the internal and external tape
drives. The internal tape drive is a 5.25-inch form factor tape drive for
integration into an enclosure. The external tape drive is a standalone unit that
can fit on a desktop.
Figure 7-1 shows the dimensions of the internal tape drive. Figure 7-2 shows
the dimensions of the external tape drive.
Note: Dimensions are shown in millimeters with inches in parenthesis.
Table 7-6 Size and weight
Specification Internal Tape Drive External Tape Drive
Depth
Depth (with bezel)
41.5 mm (1.63 in)
42.6 mm (1.68 in)
86.0 mm (3.38 in)
Length 203.0 mm (8.0 in) 285.0 mm (11.25 in)
Width
Width (with bezel)
146.0 mm (5.75 in)
149.2 mm (5.87 in)
227.0 mm (8.93 in)
Weight 1.0 kg (2.2 lbs) 3.0 kg (6.6 lbs)
Figure 7-1 Physical dimensions of the internal tape drive
5.3
(.208)
3
146
(5.75)
149.2
(5.87)
42.6
(1.68)
203.0
(8.0)
41.5
(1.63)
